ADM8832ACPZ
| Manufacturer | |
| Description | Charge Pump INV/STPUP 5.1V/15.3V/-10.2V 4mA/0.05mA/-0.05mA 20-Pin LFCSP EP IC CHARGE PUMP REG TFT 20LFCSP ADM8832ACPZ, Charge Pump Inverting, Step Up, -10.2, 5.1, 15.3V, 20-Pin, LFCSP EP LED Lighting Drivers Reg for TFT Panel |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Trays | Factory Pack Quantity | 490 |
| Standard Package Name | LFCSP | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| Frequency | 100 kHz | Power - Rated | 3.55 W |
| Converter Type | Inverting, Step Up | Voltage Rating | 5.1|15.3|-10.2 V |
| Current - Output | 4|0.05|-0.05 mA | Current - Supply | 400 uA |
| Voltage - Supply | -10.2V, 5.1V, 15.3V | Number of Outputs | 3 |
| Voltage - Input (Min) | -10.2V, 5.1V, 15.3V | Voltage - Supply (Min) | 3.6 V |
| Power - Average Forward | 3.55 W | Common Mode Transient Immunity (Min) | Industrial |
Mechanical
| Width | 4mm | Height | 0.83mm |
| Length | 4mm | Packaging | Tray |
| Lead Style | No Lead | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Package / Case | 20LFCSP EP |
| Package Cooled | LFCSP EP | Length - Overall | 4 |
| Package Quantity | LFCSP EP | Size / Dimension | 4 x 4 x 0.83mm |
| Number of Positions | 20 | Shell Size - Insert | 0.83 |
| Supplier Device Package | 20-LFCSP (4x4) | ||
Product Info
| Series | ADM8832 | Function | Inverting/Step Up |
| Applications | Converter, TFT, LCD | Manufacturer | Analog Devices |
| Output Configuration | Surface Mount | Printed Circuit Board | 20 |
Environmental
| Operating Temperature | -40 to 85 °C | ||
