ADM8832ACPZ-REEL7
| Manufacturer | |
| Description | Charge Pump INV/STPUP 5.1V/15.3V/-10.2V 4mA/0.05mA/-0.05mA 20-Pin LFCSP EP T/R IC CHARGE PUMP REG TFT 20LFCSP LED Lighting Drivers Charge Pump Regulator for TFTDisplays IC |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | ADM8832ACPZ-REEL7CT | Standard Package | Tape & Reel |
| Standard Package Name | LFCSP | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| Voltage Rating | 5.1|15.3|-10.2 V | Current - Output | 4|0.05|-0.05 mA |
| Voltage - Supply | -10.2V, 5.1V, 15.3V | Number of Outputs | 3 |
| Voltage - Input (Min) | -10.2V, 5.1V, 15.3V | Voltage - Supply (Min) | 3.6 |
| Common Mode Transient Immunity (Min) | Industrial | ||
Mechanical
| Width | 4 | Packaging | Tape and Reel |
| Lead Style | No Lead | Mounting Type | Surface Mount |
| Package / Case | 20LFCSP EP | Length - Overall | 4 |
| Package Quantity | LFCSP EP | Number of Positions | 20 |
| Shell Size - Insert | 0.83 | Supplier Device Package | 20-LFCSP (4x4) |
Product Info
| Series | ADM8832 | Function | Inverting/Step Up |
| Applications | Converter, TFT, LCD | Output Configuration | Surface Mount |
| Printed Circuit Board | 20 | ||
Environmental
| Operating Temperature | -40 to 85 °C | ||
