ADM1063ASUZ
| Manufacturer | |
| Description | Volt Supervisor Sequencer 48-Pin TQFP IC SUPERVISOR/SEQUENCER 48-TQFP Supervisory Circuits Multisupply Supvsr Sequencer w/ ADC , 10通道 电压监控器, 0.573V, 手动复位功能, 用于多电源监控器, 48针 TQFP封装 |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Trays | Factory Pack Quantity | 250 |
Compliance
| RoHS | Lead free / RoHS Compliant | Rad Hardened | No |
Electrical
| Reset | Manual Reset | Output | Programmable |
| Output Type | Open Collector / Drain & Push-Pull | Input Signal | Chip Enable |
| Voltage Rating | 3 V | Watchdog Timer | Yes |
| Current - Supply | 6000 uA | Number of Inputs | 10 Input |
| Voltage - Supply | 5.4 V, 14.4 V | Voltage - Clamping | 0.573 V, 1.25 V, 2.5 V, 6 V |
| Voltage - Threshold | Adjustable/Selectable | Voltage - Input (Min) | 0.573 V |
| Voltage - Output (Max) | 24V | Voltage - Supply (Min) | 6 V |
| Number of Voltages Monitored | 10 | Voltage - Input Offset (Max) | -5V |
Mechanical
| Width | 7mm | Height | 1.05mm |
| Length | 9mm | Packaging | Tray |
| Reset Force | 是 | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Number of Pins | 48 |
| Package / Case | 48TQFP | Package Cooled | TQFP |
| Package Quantity | TQFP | Size / Dimension | 9 x 7 x 1.05mm |
| Number of Positions | 48 | Supplier Device Package | 48-TQFP (7x7) |
Product Info
| Type | Power Supply Sequencer | Series | ADM1063 |
| Manufacturer | Analog Devices | Programmable | Yes |
| Battery Series | No Backup | Development Kit | EVAL-ADM1063TQEBZ |
| Number of Supervisors | 10 | Number of Monitor Fields | 10 |
Environmental
| Operating Temperature | -40 to 85 °C | ||
