ADM1063ACPZ
| Manufacturer | |
| Description | Volt Supervisor Sequencer 40-Pin LFCSP EP IC SEQUENCER/SUPERVISOR 40LFCSP ADM1063ACPZ, Voltage Supervisor 10-channel 0.573V Manual Reset Power Supply Sequencer 40-Pin LFCSP EP Supervisory Circuits Multisupply Supvsr Sequencer w/ ADC SUPERVISOR PROG, SMD, 1063, LFCSP40 Analog Devices , 10通道 电压监控器, 0.573V, 手动复位功能, 用于电源序列发生器, 40针 LFCSP封装 |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Trays | Factory Pack Quantity | 490 |
| Standard Package Name | LFCSP | ||
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85423190 |
| Part Status | :1063 | ||
Electrical
| Reset | Yes | Output | Open Collector/Push-Pull |
| Output Type | Open Collector / Drain & Push-Pull | Input Signal | Chip Enable |
| Voltage Rating | 3 V | Watchdog Timer | Yes |
| Clock Frequency | :400kHz | Current - Output | :4.2mA |
| Current - Supply | 6000 uA | Voltage - Supply | 5.4 V, 14.4 V |
| Voltage - Clamping | 0.573 V, 1.25 V, 2.5 V, 6 V | Voltage - Threshold | Adjustable/Selectable |
| Voltage - Input (Min) | 0.573 V | Voltage - Supply (Min) | 6 V |
| Voltage - Supply, Digital | Power Supply Sequencer | Number of Bits per Element | :12 |
| Number of Voltages Monitored | 10 | Common Mode Transient Immunity (Min) | Industrial |
Mechanical
| Width | 6mm | Height | 0.83mm |
| Length | 6mm | Weight | 0.000076 |
| Packaging | Tray | Lead Style | No Lead |
| Termination | :SMD | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Number of Pins | :40 |
| Package / Case | 40LFCSP EP | Package Cooled | LFCSP EP |
| Material Finish | :MSL 3 - 168 hours | Length - Overall | 6 |
| Package Quantity | LFCSP EP | Size / Dimension | 6 x 6 x 0.83mm |
| Number of Positions | 40 | Shell Size - Insert | 0.83 |
| Supplier Device Package | 40-LFCSP-VQ (6x6) | ||
Product Info
| Type | Power Supply Sequencer | Series | ADM1063 |
| Base Unit | :1063 | Battery Series | No Backup |
| DigiKey Programmable | Yes | Number of Supervisors | 10 |
| Printed Circuit Board | 40 | Number of Logic Elements/Cells | :10 |
Environmental
| Operating Temperature | -40 to 85 °C | ||
Documents & Media
PDF Document
PDF Document
Similar Parts
EVAL-ADM1063TQEBZ
