ADIS16223CMLZ
| Manufacturer | |
| Description | Accelerometer Triple ±70g 3.3V 14-Pin Tray SENSOR VIBRATION -70+70G MODUL Accelerometers Digital Tri-axial Vibration Sensor |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Boxed | Factory Pack Quantity | 12 |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| Output Type | Digital | Sensitivity | 4.768mg/LSB |
| Sensor Type | Acceleration | Power - Rated | 3.15 V ~ 3.6 V / 43mA |
| Sensing Angle | X, Y, Z | Sensing Range | -70 ~ 70 g |
| Voltage Rating | 3.15 | Current - Output | 43 mA |
| Voltage - Supply | 3.15 to 3.6 V | Digital I/O Lines | SPI |
| Voltage - Supply (Min) | 3.6 | ||
Mechanical
| Axis | Triple | Packaging | Tray |
| Termination | Rectangular Connector - 14 Pos | Acceleration | ±70 g |
| Mounting Type | Screw | Package / Case | 14-Module with Connector |
| Number of Positions | 14 | ||
Product Info
| Series | ADIS16223 | Features | Programmable |
Environmental
| Operating Temperature | -40 to 125 °C | ||
