ADIS16060BCCZ
| Manufacturer | |
| Description | Yaw Rate Gyroscope 16-Pin LGA MEMS Gyroscopes Single Axis ±80°/s 16-Pin LGA Tray IC GYROSCOPE YAW RATE SPI 16LGA ADIS16060BCCZ, Accelerometer, 16-Pin LGA Gyroscopes Wide BW Yaw Rate w/ SPI |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Trays | Factory Pack Quantity | 260 |
| Standard Package Name | LGA | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| Speed | ±80 | Output Type | SPI |
| Range deg/s | ±80°/s | Sensitivity | 0.0122°/sec/LSB |
| Sensing Angle | Single | Current - Output | 4.3mA |
| Voltage - Supply | 4.75 V ~ 5.25 V | Digital I/O Lines | SPI |
| Current Rating (Max) | Yes | Noise - 0.1Hz to 10Hz | 0.04 |
| Voltage - Supply (Min) | 5.25 | ||
Mechanical
| Axis | Single | Width | 8.2mm |
| Height | 5.2mm | Length | 8.35mm |
| Bandwidth | 1kHz | Packaging | 5 |
| Mounting Type | Surface Mount | Package / Case | 16LGA |
| Package Cooled | LGA | Operating Force | 2000 |
| Length - Overall | 8.35(Max) | Package Quantity | LGA |
| Size / Dimension | 8.35 x 8.2 x 5.2mm | Number of Positions | 16 |
| Shell Size - Insert | 5.2(Max) | Supplier Device Package | 16-LGA (8.2x8.2) |
Product Info
| Series | ADIS16060 | Technology | MEMS |
| Measuring Range | +/- 80 deg/s | Printed Circuit Board | 16 |
Environmental
| Operating Temperature | -40 to 105 °C | ||
