ADF4360-9BCPZ
| Manufacturer | |
| Description | PLL Frequency Synthesizer Single 24-Pin LFCSP EP IC SYNTHESIZER W/ADJ VCO 24LFCSP ADF4360-9BCPZ, PLL Frequency Synthesizer, 1.1 to 400MHz, 24-Pin CP 24 2 Phase Locked Loops - PLL Clock Generator w/ Intg VCO SYNTHESIZER, W/ADJ, VCO, 24LFCSP Analog Devices 1.1 → 400 MHz 频率合成器 , 24针 CP 24 2封装 |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | ADF43609BCPZ | Standard Package | Trays |
| Factory Pack Quantity | 490 | Standard Package Name | LFCSP |
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85423990 |
| Rad Hardened | No | ||
Electrical
| PLL | Yes | Input | CMOS, TTL |
| Output | Clock | Frequency | :400MHz |
| Interface | :Serial | Voltage Rating | 3 V |
| Frequency - Max | 250 MHz | Frequency - Min | 1.1MHz |
| Frequency Range | 1.1 to 400 MHz | Current - Output | 40 mA |
| Current - Supply | 5 mA | Voltage - Supply | 3.3 V |
| Number of Outputs | :3 | Divider/Multiplier | Yes/No |
| Number of Elements | 1 | Ratio - Input:Output | 1:2 |
| Voltage - Supply (Min) | 3.6 V | Minimum Input Frequency | 10 MHz |
| Differential - Input:Output | No/No | ||
Mechanical
| Width | 4mm | Height | 0.83mm |
| Length | 4mm | Weight | 0.299 |
| Packaging | Tray | Lead Style | No Lead |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Number of Pins | :24 | Package / Case | 24LFCSP EP |
| Package Cooled | CP 24 2 | Material Finish | :MSL 3 - 168 hours |
| Length - Overall | 4 | Package Quantity | LFCSP EP |
| Size / Dimension | 4 x 4 x 0.83mm | Number of Positions | 24 |
| Shell Size - Insert | 0.83 | Supplier Device Package | 24-LFCSP-VQ (4x4) |
Product Info
| Type | PLL Frequency Synthesizer | Series | ADF4360-9 |
| DELETED | Compliant | Programmable | No |
| Number of Circuits | 1 | RF Family/Standard | ADF4360-9 |
| Other Specifications | 10 MHz | Printed Circuit Board | 24 |
Environmental
| Operating Temperature | -40 to 85 °C | ||
