ADF4360-8BCPZ
| Manufacturer | |
| Description | Integrated Synthesizer 24-Pin LFCSP EP IC SYNTHESIZER VCO 24-LFCSP ADF4360-8BCPZ, Frequency Synthesizer, 24-Pin LFCSP EP Phase Locked Loops - PLL Intg Integer-N VCO Out Freq 65-400 IC, SYNTHESIZER / VCO, 24LFCSP 频率合成器, 24针 LFCSP封装 |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | ADF43608BCPZ | Standard Package | Trays |
| Factory Pack Quantity | 490 | Standard Package Name | LFCSP |
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85423190 |
Electrical
| PLL | Yes | Input | CMOS, TTL |
| Output | Clock | Frequency | :400MHz |
| Frequency - Max | 400MHz | Frequency Range | 65 MHz to 400 MHz |
| Current - Output | 40 mA | Voltage - Supply | 3 V ~ 3.6 V |
| Divider/Multiplier | Yes/No | Ratio - Input:Output | 1:2 |
| Minimum Input Frequency | 65 MHz | Differential - Input:Output | No/No |
Mechanical
| Width | 4mm | Height | 0.83mm |
| Length | 4mm | Weight | 0.00012 |
| Packaging | Tray | Lead Style | No Lead |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Number of Pins | :24 | Package / Case | 24LFCSP EP |
| Package Cooled | LFCSP EP | Material Finish | :MSL 3 - 168 hours |
| Length - Overall | 4 | Package Quantity | LFCSP EP |
| Size / Dimension | 4 x 4 x 0.83mm | Number of Positions | 24 |
| Shell Size - Insert | 0.83 | Supplier Device Package | 24-LFCSP-VQ (4x4) |
Product Info
| Type | Fanout Distribution, Integer N Synthesizer (RF) | Series | ADF4360-8 |
| Plug Type | :Synthesizer and VCO | Card Standard | Integrated Synthesizer |
| Number of Circuits | 1 | RF Family/Standard | ADF4360-8 |
| Printed Circuit Board | 24 | ||
Environmental
| Operating Temperature | -40 to 85 °C | ||
