ADF4360-6BCPZRL
| Manufacturer | |
| Description | PLL Frequency Synthesizer Single 24-Pin LFCSP EP T/R IC SYNTHESIZER VCO 24LFCSP Phase Locked Loops - PLL Intg Integer-N VCO Out Freq 1050-1250 |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Tape & Reel | Standard Package Name | LFCSP |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| PLL | Yes | Input | CMOS, TTL |
| Output | Clock | Voltage Rating | 3 |
| Frequency - Max | 250 MHz | Frequency Range | 1050 to 1250 MHz |
| Current - Output | 45 mA | Voltage - Supply | 3.3 V |
| Divider/Multiplier | Yes/No | Number of Elements | 1 |
| Ratio - Input:Output | 1:2 | Voltage - Supply (Min) | 3.6 |
| Minimum Input Frequency | 10 MHz | Differential - Input:Output | No/No |
Mechanical
| Width | 4 | Packaging | Tape and Reel |
| Lead Style | No Lead | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Package / Case | 24LFCSP EP |
| Length - Overall | 4 | Package Quantity | LFCSP EP |
| Number of Positions | 24 | Shell Size - Insert | 0.83 |
| Supplier Device Package | 24-LFCSP-VQ (4x4) | ||
Product Info
| Type | PLL Frequency Synthesizer | Series | ADF4360-6 |
| Number of Circuits | 1 | RF Family/Standard | ADF4360 |
| Printed Circuit Board | 24 | ||
Environmental
| Operating Temperature | -40 to 85 °C | ||
