ADF4007BCPZ-RL
| Manufacturer | |
| Description | PLL Frequency Synthesizer Single 20-Pin LFCSP EP T/R IC DIVIDER/PLL SYNTHESZR 20LFCSP Phase Locked Loops - PLL High Freq Divider/ Synthesizer |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Tape & Reel | Standard Package Name | LFCSP |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| PLL | Yes | Input | CMOS, TTL |
| Output | Clock | Voltage Rating | 2.7 |
| Frequency - Max | 7500 MHz | Current - Output | 13 mA |
| Current - Supply | 17 | Voltage - Supply | 3 V |
| Divider/Multiplier | Yes/No | Number of Elements | 1 |
| Ratio - Input:Output | 2:1 | Voltage - Supply (Min) | 3.3 |
| Minimum Input Frequency | 20 MHz | Differential - Input:Output | Yes/No |
| Common Mode Transient Immunity (Min) | Industrial | ||
Mechanical
| Width | 4 | Packaging | Tape and Reel |
| Lead Style | No Lead | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Package / Case | 20LFCSP EP |
| Length - Overall | 4 | Package Quantity | LFCSP EP |
| Number of Positions | 20 | Shell Size - Insert | 0.83 |
| Supplier Device Package | 20-LFCSP-VQ (4x4) | ||
Product Info
| Type | PLL Frequency Synthesizer | Series | ADF4007 |
| Number of Circuits | 1 | RF Family/Standard | ADF4007 |
| Printed Circuit Board | 20 | ||
Environmental
| Operating Temperature | -40 to 85 °C | ||
