ADCLK925BCPZ-R7
| Manufacturer | |
| Description | Clock Fanout Buffer 4-OUT 16-Pin LFCSP EP T/R IC CLK BUFFER 1:2 7.5GHZ 16LFCSP Clock Buffer Ultrafast SiGe ECL |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | ADCLK925BCPZ-R7CT | Standard Package | Cut Tape |
| Factory Pack Quantity | 1500 | Standard Package Name | LFCSP |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| Input | Clock | Output | ECL, NECL, PECL |
| Current Ratio | 1:2 | Voltage Rating | -2.375|2.375 V |
| Frequency - Max | 7.5GHz | Voltage - Output | ECL |
| Voltage - Supply | -2.5|-3.3|2.5|3.3 V | Number of Outputs | 4 |
| Frequency - Output 1 | 6000 MHz | Ratio - Input:Output | 1:2 |
| Voltage - Supply (Min) | -3.63|3.63 V | Input Logic Level - Low | ECL |
| Propagation Delay (Max) | 0.095 ns (Typ) at 3.3 V | Differential - Input:Output | Yes/Yes |
| Max Propagation Delay @ V, Max CL | 0.095(Typ)@3.3V ns | Common Mode Transient Immunity (Min) | Extended Industrial |
Mechanical
| Width | 3 | Height | 0.83 mm |
| Length | 3 mm | Packaging | Tape and Reel |
| Lead Style | No Lead | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Package / Case | 16LFCSP EP |
| Length - Overall | 3 | Package Quantity | LFCSP EP |
| Number of Positions | 16 | Shell Size - Insert | 0.83 |
| Supplier Device Package | 16-LFCSP-VQ (3x3) | ||
Product Info
| Type | Fanout Buffer | Series | ADCLK925 |
| Manufacturer | Analog Devices | Number of Circuits | 1 |
| Printed Circuit Board | 16 | ||
Environmental
| Operating Temperature | -40°C ~ 125°C | ||
