ADCLK925BCPZ-R2
| Manufacturer | |
| Description | Clock Fanout Buffer 4-OUT 16-Pin LFCSP EP T/R IC CLK BUFFER 1:2 7.5GHZ 16LFCSP Clock Buffer Ultrafast SiGe ECL 1输入 ECL系列 时钟/数据缓冲器, ECL输出, 16针 LFCSP VQ封装 |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Tape & Reel | Factory Pack Quantity | 250 |
| Standard Package Name | LFCSP | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| Input | Clock | Output | ECL, NECL, PECL |
| Input Type | ECL | Logic Type | ECL |
| Current Ratio | 1:2 | Operating Mode | 差分，单端 |
| Voltage Rating | -2.375|2.375 V | Frequency - Max | 7.5GHz |
| Voltage - Output | ECL | Voltage - Supply | -2.5|-3.3|2.5|3.3 V |
| Number of Outputs | 4 | Frequency - Output 1 | 6000 MHz |
| Ratio - Input:Output | 1:2 | Voltage - Supply (Min) | -3.63|3.63 V |
| Input Logic Level - Low | ECL | Propagation Delay (Max) | 0.095 ns (Typ) at 3.3 V |
| Differential - Input:Output | Yes/Yes | Max Propagation Delay @ V, Max CL | 0.095(Typ)@3.3V ns |
| Common Mode Transient Immunity (Min) | Extended Industrial | ||
Mechanical
| Width | 3mm | Height | 0.85mm |
| Length | 3mm | Packaging | Tape and Reel |
| Lead Style | No Lead | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Number of Pins | 16 |
| Package / Case | 16LFCSP EP | Package Quantity | LFCSP EP |
| Size / Dimension | 3 x 3 x 0.85mm | Number of Positions | 16 |
| Supplier Device Package | 16-LFCSP-VQ (3x3) | ||
Product Info
| Type | Fanout Buffer | Series | ADCLK925 |
| Function | Y | Manufacturer | Analog Devices |
| Number of Circuits | 1 | ||
Environmental
| Operating Temperature | -40°C ~ 125°C | ||
