ADAU1761BCPZ
| Manufacturer | |
| Description | Audio Codec 2ADC / 2DAC 24-Bit 32-Pin LFCSP EP IC SIGMADSP CODEC PLL 32LFCSP ADAU1761BCPZ, Audio Codec 2 (ADC), 2 (DAC)-channel 24bit- 96ksps Serial-I2C, Serial-SPI 32-Pin LFCSP EP Audio DSPs Low Pwr 96kHz 24B w/ Intg PLL AUDIO CODEC, 24BIT, 96KSPS, LFCSP-32 IC, AUDIO CODEC, 24BIT, 96KHZ, LFCSP-32 立体声通道 96ksps 24bit 音频编解码器, 串行I2C、串行SPI接口, 32针 LFCSP封装 Interface - CODECs Low Pwr 96kHz 24B w/ Intg PLL |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Trays | Factory Pack Quantity | 490 |
| Standard Package Name | LFCSP | ||
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85423190 |
| Rad Hardened | No | ||
Electrical
| Coil Type | :Stereo | Interface | Serial (I2C, SPI) |
| Resolution | 24 bit | Sigma Delta | Yes |
| Data Interface | Serial | Voltage Rating | 1.5 V, 3.3 V |
| Data Rate (Max) | 96 kHz | Number of DAC's | 4 |
| Number of Inputs | :3 | Voltage - Supply | 1.5|3.3 V |
| Power Supply Type | Analog|Digital | Resolution (Bits) | 24 Bit |
| Number of Channels | 2ADC /2 DAC | Sampling Frequency | 96 ksps |
| Number of ADCs / DACs | 3 | Voltage - Supply (Min) | 1.8 V |
| Voltage - Supply, Analog | 1.8 V ~ 3.65 V | Voltage - Supply, Digital | 1.63V ~ 3.65V |
| Sampling Rate (Per Second) | 96 KSPS | S/N Ratio, ADCs / DACs (db) Typ | 99 db |
| Common Mode Transient Immunity (Min) | Industrial | ||
Mechanical
| Width | 5mm | Height | 0.83mm |
| Length | 5mm | Weight | 0.00001 |
| Packaging | Tray | Lead Style | No Lead |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Number of Pins | :32 | Package / Case | 32LFCSP EP |
| Package Cooled | LFCSP EP | Package Quantity | LFCSP EP |
| Size / Dimension | 5 x 5 x 0.83mm | Number of Positions | 32 |
| Supplier Device Package | 32-LFCSP-VQ (5x5) | ||
Product Info
| Type | General Purpose | Series | ADAU1761 |
| Number of A/D Converters | 4 | ||
Environmental
| Operating Temperature | -40°C ~ 85°C | Operating Temperature - Junction | 85C |
