AD9760ARZ
| Manufacturer | |
| Description | DAC 1-CH 10-bit 28-Pin SOIC W IC DAC 10BIT 125MSPS 28-SOIC AD9760ARZ, 10-Bit 10 Bit DAC 125Msps, Parallel, 28-Pin SOIC W Digital to Analog Converters - DAC 10-Bit 100 MSPS DAC, 10BIT, 125MSPS, 0.5LSB, 28SOIC Analog Devices , 10 位 DAC, 125Msps, 并行接口, 28针 SOIC W封装 |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Rail / Tube | Factory Pack Quantity | 27 |
| Standard Package Name | SOIC W | ||
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85423990 |
| Rad Hardened | No | ||
Electrical
| Interface | Parallel | Full Scale | 10 %FSR |
| Input Type | :Parallel | Resolution | 10 Bit |
| Output Type | Current | INL/DNL (LSB) | ±1 LSB |
| Power - Input | Analog and Digital | Settling Time | 0.035(Typ) us |
| Converter Type | General Purpose | Data Interface | :Parallel |
| Number of Bits | 10 | Data Rate (Max) | 125 Msps |
| Number of DAC's | 1 | Current - Output | :25mA |
| Voltage - Supply | 5.5 V | Distortion Rating | +/- 1 LSB |
| Number of Outputs | 1 | Power Supply Type | Analog and Digital |
| Resolution (Bits) | :10bit | Voltage Reference | Internal, External |
| Number of Channels | 1 | Sampling Frequency | :125MSPS |
| Voltage Supply Source | Analog and Digital | Power Dissipation (Max) | 175 mW |
| Number of Outputs and Type | 2 Current, Unipolar; 2 Current, Bipolar | Sampling Rate (Per Second) | 125M |
| Voltage - Supply Span (Typ) | Not Required V | Common Mode Transient Immunity (Min) | Industrial |
Mechanical
| Width | 7.6(Max) | Weight | 0.000426 |
| Packaging | Tube | Lead Style | Gull-wing |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Number of Pins | :28 | Package / Case | 28SOIC W |
| Package Cooled | SOIC W | Material Finish | :MSL 1 - Unlimited |
| Length - Overall | 18.1(Max) | Package Quantity | SOIC W |
| Number of Positions | 28 | Shell Size - Insert | 2.35(Max) |
| Supplier Device Package | 28-SOIC | ||
Product Info
| Series | AD9760 | Printed Circuit Board | 28 |
| Number of A/D Converters | 1 | ||
Environmental
| Operating Temperature | -40 to 85 °C | Operating Temperature - Junction | 85C |
