AD9516-4BCPZ
| Manufacturer | |
| Description | Clock Generator 64-Pin LFCSP EP Tray IC CLOCK GEN 1.6GHZ VCO 64-LFCSP AD9516-4BCPZ, PLL Clock Synthesizer, 64-Pin LFCSP VQ Clock Generators & Support Products 14-Output w/ Intg 1.6GHz VCO CLOCK GENERATOR, 1.8GHZ, LFCSP-64 DIFF FANOUT BUFFER, 1.8GHZ, LFCSP-64 |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | AD95164BCPZ | Standard Package | Trays |
| Factory Pack Quantity | 260 | Standard Package Name | LFCSP |
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85411000 |
| Rad Hardened | No | ||
Electrical
| PLL | Yes | Input | Clock |
| Output | CMOS, LVDS, LVPECL | Frequency | :1.8GHz |
| Output Type | LVPECL | Frequency - Max | 2.95GHz |
| Voltage - Supply | 3.135 V ~ 3.465 V | Number of Outputs | 14 |
| Divider/Multiplier | Yes/No | Frequency - Output 1 | 1800 MHz |
| Ratio - Input:Output | 1:14 | Differential - Input:Output | Yes/Yes |
| Common Mode Transient Immunity (Min) | Industrial | ||
Mechanical
| Width | 9mm | Height | 0.83mm |
| Length | 9mm | Weight | 0.000001 |
| Packaging | Tray | Lead Style | No Lead |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Number of Pins | :64 | Package / Case | 64LFCSP EP |
| Package Cooled | LFCSP VQ | Length - Overall | 9 |
| Package Quantity | LFCSP EP | Size / Dimension | 9 x 9 x 0.83mm |
| Number of Positions | 64 | Shell Size - Insert | 0.83 |
| Supplier Device Package | 64-LFCSP-VQ (9x9) | ||
Product Info
| Type | Clock Generator, Fanout Distribution | Series | AD9516-4 |
| DELETED | Compliant | Function | Clock Generator |
| Number of Circuits | 1 | RF Family/Standard | AD9516-4 |
| Printed Circuit Board | 64 | ||
Environmental
| Operating Temperature | -40 to 85 °C | Operating Temperature - Junction | 85C |
