AD8339ACPZ
| Manufacturer | |
| Description | Quadrature Dmod 50MHz 40-Pin LFCSP EP IC I/Q DEMOD QUAD 50MHZ 40-LFCSP Modulator / Demodulator DC to 50MHz Quad I/Q IC, DUAL IQ DEMODULATOR , 正交 解调器, -1.3 (Typical)dB, 50MHz, ±4.5 → ±5.5 V, 40针 LFCSP VQ封装 |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Trays | Factory Pack Quantity | 490 |
| Standard Package Name | LFCSP | ||
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85423190 |
Electrical
| Gain | -1.3(Typ) dB | P1dB | 14.8dBm |
| Modulation | Quadrature | LO Frequency | 0Hz ~ 200MHz |
| Noise Figure | 11.5 dB | RF Frequency | 0Hz ~ 50MHz |
| Voltage Rating | ±4.5 | Frequency - Max | 50 MHz |
| Frequency - Min | :0.01MHz | Frequency Range | :0Hz to 50MHz |
| Current - Output | 35mA | Current - Supply | 0.035(Typ) |
| Voltage - Supply | 4.5 V ~ 5.5 V | Voltage - Supply (Min) | ±5.5 |
| Power Dissipation (Max) | 2000 | Common Mode Transient Immunity (Min) | Industrial |
Mechanical
| Width | 6 | Weight | 0.0001 |
| Packaging | Tray | Lead Style | No Lead |
| Termination | :SMD | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Number of Pins | :40 |
| Package / Case | 40LFCSP EP | Material Finish | :MSL 3 - 168 hours |
| Length - Overall | 6 | Package Quantity | LFCSP EP |
| Number of Positions | 40 | Shell Size - Insert | 0.83 |
| Supplier Device Package | 40-LFCSP-VQ (6x6) | ||
Product Info
| Type | Demodulator | Series | AD8339 |
| RF Type | :Quadrature | Function | Demodulator |
| Base Unit | :8339 | Programmable | Yes |
| Printed Circuit Board | 40 | ||
Environmental
| Operating Temperature | :-40°C | ||
