AD7793BRUZ
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Rail / Tube | Factory Pack Quantity | 96 |
| Standard Package Name | TSSOP | ||
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85423990 |
| Rad Hardened | No | ||
Electrical
| Interface | Serial (3-Wire, SPI, QSPI, Microwire) | Linearity | :15ppm |
| Input Type | Voltage | Resolution | 24 Bit |
| Input Signal | Differential | INL/DNL (LSB) | ±15ppm of FSR |
| Power - Input | Single | Converter Type | General Purpose |
| Data Interface | DSP, MICROWIRE™, QSPI™, Serial, SPI™ | Input Polarity | Bipolar |
| Number of Bits | 24 | Voltage Rating | ±2.5V |
| Data Rate (Max) | 4.17 to 470 SPs | Voltage - Rated | �2.5 |
| Current - Output | :450µA | Voltage - Supply | 3.3 V, 5 V |
| Resolution (Bits) | :24bit | Voltage Reference | Internal|External |
| Number of Channels | 3 Channel | Number of Elements | 1 |
| Sampling Frequency | 470 sps | Number of ADCs / DACs | 1 |
| Voltage Supply Source | Single | Power Dissipation (Max) | 2.5 mW |
| Voltage - Supply, Digital | :2.7V to 5.25V | Voltage Supply - Internal | :2.7V to 5.25V |
| Sampling Rate (Per Second) | 500 | Differential - Input:Output | Yes |
| Voltage - Supply Span (Typ) | Not Required V | ||
Mechanical
| Width | 4.4mm | Height | 1.05mm |
| Length | 5mm | Weight | 0.0001 |
| Packaging | Tube | Lead Style | Gull-wing |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Number of Pins | :16 | Package / Case | 16TSSOP |
| Package Cooled | TSSOP | Material Finish | :MSL 1 - Unlimited |
| Length - Overall | 5 | Package Quantity | TSSOP |
| Size / Dimension | 5 x 4.4 x 1.05mm | Number of Positions | 16 |
| Shell Size - Insert | 1.05(Max) | Supplier Device Package | 16-TSSOP |
Product Info
| Series | AD7793 | Base Unit | :7793 |
| Architecture | Delta-Sigma | Printed Circuit Board | 16 |
| Number of A/D Converters | 3 | Number of Inputs and Type | 3 Differential, Unipolar; 3 Differential, Bipolar |
Environmental
| Operating Temperature | -40°C ~ 105°C | ||
Documents & Media
Sourcing & traceability
- Datasheet
- AD7792_7793.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
