AD7685ARMZ

Manufacturer	Analog Devices, Inc.
Description	ADC Single SAR 250ksps 16-bit Serial 10-Pin MSOP Tube Single ADC SAR 250ksps 16-bit Serial 10-Pin MSOP Tube IC ADC 16BIT PSEUDO-DIFF 10-MSOP AD7685ARMZ, 16-Bit Analogue to Digital Converter, Differential, Serial, 10-Pin MSOP Analog to Digital Converters - ADC 16-Bit 100 kSPS ADC, 16BIT, PSEUDO-DIFF, 10-MSOP Analog Devices , 16 位 ADC, 差分输入, 串行接口, 10针 MSOP封装
Category	Integrated CircuitsData ConvertersAnalog-to-Digital Converters (ADC)

对参数有疑问？问 AI 助手

Business

Standard Package	Rail / Tube	Factory Pack Quantity	50
Standard Package Name	MSOP

Interface	Serial (3-Wire, 4-Wire, SPI, QSPI, Microwire)	S/N Ratio	90(Typ) dB
Input Type	Voltage	Resolution	16 Bit
Input Signal	Pseudo-Differential	INL/DNL (LSB)	±6LSB
Power - Input	Single	Power - Rated	15 W
Converter Type	General Purpose	Data Interface	DSP, MICROWIRE™, QSPI™, Serial, SPI™
Input Polarity	Unipolar	Number of Bits	16
Voltage Rating	5.8V	Data Rate (Max)	250 kSPs
Ratio - S/H:ADC	Yes	Voltage - Rated	5.8
Voltage - Supply	2.5 V, 3.3 V, 5 V	Resolution (Bits)	:16bit
Voltage Reference	External	Number of Channels	1 Channel
Number of Elements	1	Sampling Frequency	250 ksps
Number of ADCs / DACs	1	Voltage Supply Source	Single
Power Dissipation (Max)	15 mW	Voltage Supply - Internal	:2.3V to 5.5V
Sampling Rate (Per Second)	250k	Differential - Input:Output	Yes
Voltage - Supply Span (Typ)	Not Required V	S/N Ratio, ADCs / DACs (db) Typ	93.5 dB
