AD5535ABCZ
| Manufacturer | |
| Description | DAC 32-CH Resistor-String 14-bit 124-Pin CSP-BGA Tray IC DAC 14BIT SRL 124CSPBGA DAC 32-Ch 14-Bit, Amp 50-200V CSPBGA124 Digital to Analog Converters - DAC IC 32-CH w/ 200V AMP |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Trays | Factory Pack Quantity | 126 |
| Standard Package Name | BGA | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Rad Hardened | No | ||
Electrical
| Interface | Serial (3-Wire, SPI) | Resolution | 14 Bit |
| Output Type | Voltage | INL/DNL (LSB) | ±0.1(Typ) %FSR |
| Power - Input | Dual | Settling Time | 65(Typ) us |
| Converter Type | General Purpose | Data Interface | Serial |
| Number of Bits | 14 | Data Rate (Max) | 1.2 Msps |
| Number of DAC's | 32 | Voltage - Supply | 5.25 V |
| Distortion Rating | +/- 0.1 % FSR | Number of Outputs | 32 |
| Power Supply Type | Dual | Voltage Reference | External |
| Number of Channels | 32 | Voltage Supply Source | Analog and Digital |
| Power Dissipation (Max) | 787 mW | Number of Outputs and Type | 32 Voltage, Unipolar |
| Sampling Rate (Per Second) | 1.2M | Voltage - Supply Span (Typ) | �5 V |
| Common Mode Transient Immunity (Min) | Industrial | ||
Mechanical
| Width | 15 | Packaging | Tray |
| Lead Style | Ball | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Package / Case | 124CSP-BGA |
| Package Cooled | CSP-BGA | Length - Overall | 15 |
| Package Quantity | CSP-BGA | Number of Positions | 124 |
| Shell Size - Insert | 1.25(Max) | Supplier Device Package | 124-CSPBGA (15x15) |
Product Info
| Series | AD5535 | Architecture | Resistor-String |
| Printed Circuit Board | 124 | Number of A/D Converters | 32 |
Environmental
| Operating Temperature | -10 to 85 °C | Operating Temperature - Junction | 85C |
