AD5447YRU
| Manufacturer | |
| Description | DAC 2-CH R-2R 12-bit 24-Pin TSSOP IC DAC 12BIT DUAL MULT 24-TSSOP Digital to Analog Converters - DAC Dual 12-bit Parallel IOUT IC |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Rail / Tube | Factory Pack Quantity | 62 |
| Standard Package Name | TSSOP | ||
Compliance
| RoHS | Contains lead / RoHS non-compliant | EU RoHS | Not Compliant |
Electrical
| Interface | Parallel | Full Scale | ±25 mV |
| Resolution | 12 Bit | Output Type | Current |
| INL/DNL (LSB) | ±1 LSB | Settling Time | 0.12 us |
| Converter Type | General Purpose | Data Interface | Parallel |
| Number of Bits | 12 | Data Rate (Max) | 21.3 Msps |
| Number of DAC's | 2 | Voltage - Supply | 5.5 V |
| Distortion Rating | +/- 1 LSB | Number of Outputs | 2 |
| Power Supply Type | Single | Voltage Reference | External |
| Voltage Supply Source | Single Supply | Power Dissipation (Max) | 3.3 uW |
| Number of Outputs and Type | 2 Current, Unipolar; 2 Current, Bipolar | Sampling Rate (Per Second) | 21.3M |
| Common Mode Transient Immunity (Min) | Automotive | ||
Mechanical
| Packaging | Tube | Lead Style | Gull-wing |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Package / Case | 24TSSOP | Package Quantity | TSSOP |
| Number of Positions | 24 | Supplier Device Package | 24-TSSOP |
Product Info
| Series | AD5447 | Architecture | R-2R |
| Number of A/D Converters | 2 | ||
Environmental
| Operating Temperature | -40 to 125 °C | ||
