AD5422AREZ
| Manufacturer | |
| Description | DAC 1-CH Segment 16-bit 24-Pin TSSOP EP IC DAC 16BIT SER 24TSSOP DAC 16-Bit Serial 4-20mA Vout TSSOP-EP Digital to Analog Converters - DAC SGL CH 16B Current Source & Vout IC, DAC, 16BIT, SER, 24TSSOP Analog Devices 16 位 DAC, 40ksps, SPI接口, 24针 TSSOP封装 |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Rail / Tube | Factory Pack Quantity | 62 |
| Standard Package Name | TSSOP | ||
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85423190 |
| Rad Hardened | No | ||
Electrical
| Interface | Serial (3-Wire, SPI, QSPI, Microwire) | Full Scale | ±0.2 %FSR |
| Input Type | :Serial | Resolution | 16 Bit |
| Output Type | Current|Voltage | INL/DNL (LSB) | ±0.024 %FSR |
| Power - Input | Single/Dual | Settling Time | 40(Typ)|25 us |
| Converter Type | General Purpose | Data Interface | MICROWIRE™, Serial, SPI™ |
| Number of Bits | 16 | Data Rate (Max) | 40 Ksps |
| Number of DAC's | 1 | Current - Output | :3.9mA |
| Voltage - Supply | 5.5 V | Number of Outputs | 1 |
| Power Supply Type | Single|Dual | Resolution (Bits) | :16bit |
| Voltage Reference | Internal, External | Number of Channels | 1 |
| Sampling Frequency | :40kSPS | Voltage Supply Source | Analog and Digital, Dual ± |
| Power Dissipation (Max) | 158 mW | Voltage - Supply, Digital | :2.7V to 5.5V |
| Voltage Supply - Internal | :-26.4V to 0V, 10.8V to 40V | Number of Outputs and Type | 1 Current, Unipolar; 1 Current, Bipolar; 1 Voltage, Unipolar; 1 Voltage, Bipolar |
| Sampling Rate (Per Second) | 40k | Common Mode Transient Immunity (Min) | Industrial |
Mechanical
| Width | 4.4 | Weight | 0.000175 |
| Packaging | Tube | Lead Style | Gull-wing |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Number of Pins | :24 | Package / Case | 24TSSOP EP |
| Package Cooled | TSSOP EP | Material Finish | :MSL 3 - 168 hours |
| Length - Overall | 7.8 | Package Quantity | TSSOP EP |
| Number of Positions | 24 | Shell Size - Insert | 1 |
| Supplier Device Package | 24-TSSOP-EP | ||
Product Info
| Series | AD5422 | Base Unit | :5422 |
| Architecture | Segment | Printed Circuit Board | 24 |
| Number of A/D Converters | 1 | ||
Environmental
| Operating Temperature | -40 to 85 °C | Operating Temperature - Junction | 85C |
