AD1836AASZ

Manufacturer	Analog Devices, Inc.
Description	Audio Codec 2ADC / 3DAC 24-Bit 52-Pin MQFP IC CODEC 4ADC/6DAC 24 BIT 52MQFP AD1836AASZ, Audio Codec 2 (ADC), 3 (DAC)-channel 24bit- 96ksps Serial-SPI 52-Pin MQFP Interface - CODECs IC MultiCH96 kHz Codec 立体声通道 96ksps 24bit 音频编解码器, 串行 - SPI接口, 52针 MQFP封装
Category	Testing, Inspection, and Prototyping SolutionsTest LeadsTest Leads

对参数有疑问？问 AI 助手

Business

Product	Audio CODECs	Standard Package	Trays
Factory Pack Quantity	96	Standard Package Name	QFP

RoHS	Lead free / RoHS Compliant	EU RoHS	Compliant
Rad Hardened	No

Noise	- 92 dB, - 95 dB	Interface	Serial (SPI)
S/N Ratio	105 dB ADC/108 dB DAC	Resolution	24 bit
Input Range	2	Sigma Delta	Yes
Power - Input	单	Data Interface	Serial
Voltage Rating	3.3 V, 5 V	Data Rate (Max)	96 kSPs
Number of DAC's	4	Current - Output	108 mA, 78 mA
Current - Supply	108 mA, 78 mA	Voltage - Supply	3.3\|5 V
Number of Outputs	4	Power Supply Type	Analog\|Digital
Resolution (Bits)	24 Bit	Number of Channels	2ADC /3 DAC
Sampling Frequency	96 ksps	Number of ADCs / DACs	2
Voltage - Supply (Min)	3/4.75 V	Voltage - Supply, Analog	4.75 V ~ 5.25 V
Voltage - Supply, Digital	4.75 V ~ 5.25 V	Sampling Rate (Per Second)	96 KSPS
S/N Ratio, ADCs / DACs (db) Typ	105 / 108	Dynamic Range, ADCs / DACs (db) Typ	105 / 108
Common Mode Transient Immunity (Min)	Industrial
