MAX9867ETJ+
| Manufacturer | |
| Description | Audio Codec 2ADC / 2DAC 32-Pin TQFN EP IC STEREO AUD CODEC LP 32TQFN-EP Stereo Audio Codec Low Power TQFN32EP Interface - CODECs Stereo Audio CODEC for Portable Devices IC, CODEC, STEREO AUDIO, LP, 32TQFN Low-Power, Stereo Audio Codec 立体声通道 48kHz 立体声音频 音频编解码器, 串行 - I2C接口, 32针 TQFN封装 |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Rail / Tube | Factory Pack Quantity | 1 |
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85235290 | ||
Electrical
| Coil Type | Stereo Audio | Interface | Serial-I2C |
| Resolution | 18 bit | Sigma Delta | Yes |
| Data Interface | I²C, Serial | Voltage Rating | 1.8 V |
| Data Rate (Max) | 48 kSPs | Number of DAC's | 1 |
| Current - Output | 12 mA | Number of Inputs | :2 |
| Voltage - Supply | 1.8 V | Power Supply Type | Analogue, Digital |
| Resolution (Bits) | 18 b | Number of Channels | 2ADC /2 DAC |
| Sampling Frequency | 48 ksps | Number of ADCs / DACs | 2 / 2 |
| Voltage - Supply, Analog | 1.65 V ~ 1.95 V | Voltage - Supply, Digital | 1.65 V ~ 1.95 V |
| S/N Ratio, ADCs / DACs (db) Typ | 85 dB, 90 dB | Dynamic Range, ADCs / DACs (db) Typ | 85 / 90 |
Mechanical
| Width | 5.1mm | Height | 0.75mm |
| Length | 5.1mm | Weight | 0.0002 |
| Packaging | Tray | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Number of Pins | :32 |
| Package / Case | 32TQFN EP | Package Cooled | TQFN |
| Material Finish | :MSL 1 - Unlimited | Size / Dimension | 5.1 x 5.1 x 0.75mm |
| Number of Positions | 32 | Supplier Device Package | 32-TQFN-EP (5x5) |
Product Info
| Type | General Purpose | Series | MAX9867 |
Environmental
| Operating Temperature | -40°C ~ 85°C | ||
