LTM8029EY#PBF
| Manufacturer | |
| Description | Conv DC-DC Single Step Down 4.5V to 36V uModule 35-Pin BGA DC/DC CONVERT 1.2-18V 600MA |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | 273 | Standard Package Name | BGA |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Rad Hardened | No | ||
Electrical
| Isolation | Non-Isolated | Output Type | Adjustable |
| Power - Max | 11W | Voltage Rating | 36 V |
| Line Regulation | 0.3%(Typ) | Load Regulation | 0.4%(Typ) |
| Current - Output | 600mA | Number of Outputs | 1 |
| Regulator Topology | Step Down | Power (Watts) - Max | 11W |
| Switching Regulator | Yes | Voltage - Isolation | Not Required V |
| Frequency - Switching | 200 to 2200 | Voltage - Input (Min) | 1.2 ~ 18 V |
| DC Voltage - Input (Min) | 4.5 V | Common Mode Transient Immunity (Min) | Extended |
Mechanical
| Width | 6.25 | Packaging | Tray |
| Lead Style | Ball | Mounting Type | Surface Mount |
| Package / Case | 35-LGA | Package Cooled | BGA |
| Length - Overall | 11.25 | Package Quantity | BGA |
| Size / Dimension | 0.44" L x 0.25" W x 0.13" H (11.3mm x 6.3mm x 3.4mm) | Number of Positions | 35 |
| Shell Size - Insert | 2.82 | ||
Product Info
| Type | Step Down | Features | Remote On/Off, OTP, SCP |
| Printed Circuit Board | 35 | ||
Environmental
| Operating Temperature | -40°C ~ 125°C | ||
