LTC2655BIUF-L16#TRPBF
| Manufacturer | |
| Description | DAC 4-CH 16-bit 20-Pin PQFN EP T/R IC DAC 16BIT I2C/SRL 20QFN |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | 2,500 | Standard Package Name | QFN |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| Interface | Serial (2-Wire, I2C) | Resolution | 16bit |
| Output Type | Voltage | INL/DNL (LSB) | ±4LSB |
| Settling Time | 9.1µs | Converter Type | General Purpose |
| Data Interface | I²C, Serial | Number of Bits | 16 |
| Number of DAC's | 4 | Voltage - Supply | 3.3|5 |
| Power Supply Type | Single | Voltage Supply Source | Single Supply |
| Number of Outputs and Type | 4 Voltage, Bipolar | Sampling Rate (Per Second) | * |
| Common Mode Transient Immunity (Min) | Industrial | ||
Mechanical
| Width | 4 | Packaging | Tape and Reel |
| Mounting Type | Surface Mount | Package / Case | 20-WFQFN Exposed Pad |
| Length - Overall | 4 | Package Quantity | PQFN EP |
| Number of Positions | 20 | Shell Size - Insert | 0.75(Max) |
| Supplier Device Package | 20-QFN Exposed Pad (4x4) | ||
Product Info
| Printed Circuit Board | 20 | Number of A/D Converters | 4 |
Environmental
| Operating Temperature | -40°C ~ 85°C | ||
