LTC2440CGN
| Manufacturer | |
| Description | Single ADC Delta-Sigma 4ksps 24-bit Serial 16-Pin SSOP N IC ADC DIFFER 24-BIT HS 16-SSOP LTC2440CGN#PBF |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | 100 | Standard Package Name | SSOP |
Compliance
| RoHS | Contains lead / RoHS non-compliant | ||
Electrical
| Interface | Serial (2-Wire, 3-Wire, 4-Wire, S... | Input Type | Voltage |
| Resolution | 24bit | Input Signal | Differential |
| INL/DNL (LSB) | 15ppm of Vref | Converter Type | Temperature Measurement |
| Data Interface | MICROWIRE™, Serial, SPI™ | Input Polarity | Bipolar |
| Number of Bits | 24 | Voltage Rating | ±2.75V |
| Voltage - Supply | 5 | Voltage Reference | External |
| Sampling Frequency | 4ksps | Number of ADCs / DACs | 1 |
| Voltage Supply Source | Single | Differential Nonlinearity | ±1LSB(Typ) |
| Sampling Rate (Per Second) | 3.5k | Differential - Input:Output | Yes |
| Common Mode Transient Immunity (Min) | Commercial | ||
Mechanical
| Width | 3.99(Max) | Packaging | Tube |
| Lead Style | Gull-wing | Mounting Type | Surface Mount |
| Package / Case | 16-SSOP (0.154", 3.90mm Width) | Length - Overall | 4.98(Max) |
| Package Quantity | SSOP N | Number of Positions | 16 |
| Shell Size - Insert | 1.5(Max) | Supplier Device Package | 16-SSOP |
Product Info
| Architecture | Delta-Sigma | Printed Circuit Board | 16 |
| Number of A/D Converters | 2 | Number of Inputs and Type | 1 Differential, Bipolar |
Environmental
| Operating Temperature | 0°C ~ 70°C | ||
