LTC2422CMS
| Manufacturer | |
| Description | Single ADC Delta-Sigma 7.5sps 20-bit Serial 10-Pin MSOP IC ADC 2CH 20BIT MICRPWR 10-MSOP LTC2422CMS#PBF |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | 50 | Standard Package Name | MSOP |
Compliance
| RoHS | Contains lead / RoHS non-compliant | ||
Electrical
| Interface | Serial (2-Wire, 3-Wire, SPI, Micr... | Input Type | Voltage |
| Resolution | 20bit | Input Signal | Single-Ended|Pseudo-Differential |
| INL/DNL (LSB) | 20ppm of Vref | Converter Type | Temperature Measurement |
| Data Interface | MICROWIRE™, Serial, SPI™ | Input Polarity | Unipolar |
| Number of Bits | 20 | Voltage Rating | 6.188V |
| Voltage - Supply | 3.3|5 | Voltage Reference | External |
| Sampling Frequency | 7.5sps | Number of ADCs / DACs | 1 |
| Voltage Supply Source | Single | Sampling Rate (Per Second) | 7.5 |
| Differential - Input:Output | Yes | Common Mode Transient Immunity (Min) | Commercial |
Mechanical
| Width | 3 | Packaging | Tube |
| Lead Style | Gull-wing | Mounting Type | Surface Mount |
| Package / Case | 10-TFSOP, 10-MSOP (0.118", 3.00mm Width) | Length - Overall | 3 |
| Package Quantity | MSOP | Number of Positions | 10 |
| Shell Size - Insert | 0.86 | Supplier Device Package | 10-MSOP |
Product Info
| Architecture | Delta-Sigma | Printed Circuit Board | 10 |
| Number of A/D Converters | 2 | Number of Inputs and Type | 2 Single-Ended, Unipolar; 2 Pseudo-Differential, Unipolar |
Environmental
| Operating Temperature | 0°C ~ 70°C | ||
