LTC2205IUK#PBF
| Manufacturer | |
| Description | Single ADC Pipelined 65Msps 16-bit Parallel 48-Pin QFN EP IC ADC 16-BIT 65MSPS 48-QFN |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | 52 | Standard Package Name | QFN |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Rad Hardened | No | ||
Electrical
| Interface | Parallel | Linearity | �1LSB |
| Input Type | Voltage | Resolution | 16bit |
| Input Signal | Differential | INL/DNL (LSB) | ±4.5LSB |
| Power - Input | Single | Power - Rated | 776 W |
| Converter Type | General Purpose | Data Interface | Parallel |
| Input Polarity | Bipolar | Number of Bits | 16 |
| Voltage Rating | 1.5Vp-p/2.25Vp-p | Voltage - Rated | �0.75/�1.125 |
| Voltage - Supply | Not Required V | Voltage Reference | Internal|External |
| Number of Elements | 1 | Sampling Frequency | 65Msps |
| Number of ADCs / DACs | 1 | Voltage Supply Source | Single |
| Power Dissipation (Max) | 776 | Differential Nonlinearity | ±1LSB |
| Sampling Rate (Per Second) | 65M | Differential - Input:Output | Yes |
| Voltage - Supply Span (Typ) | Not Required V | Common Mode Transient Immunity (Min) | Industrial |
Mechanical
| Width | 7 | Packaging | Tube |
| Lead Style | No Lead | Mounting Type | Surface Mount |
| Package / Case | 48-WFQFN Exposed Pad | Package Cooled | QFN EP |
| Length - Overall | 7 | Package Quantity | QFN EP |
| Number of Positions | 48 | Shell Size - Insert | 0.75(Max) |
| Supplier Device Package | 48-QFN (7x7) | ||
Product Info
| Architecture | Pipelined | Printed Circuit Board | 48 |
| Number of A/D Converters | 1 | Number of Inputs and Type | 1 Differential |
Environmental
| Operating Temperature | -40°C ~ 85°C | ||
