LT3596EUHG#PBF
| Manufacturer | |
| Description | LED DRVR 30Segment 9V/12V/15V/18V/24V 39-Pin QFN EP IC LED DVR 300MA ADJ 52-VQFN IC, LED DRIVER, BUCK, QFN-52 |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | 45 | Standard Package Name | QFN |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Tariff No | 85423190 | Rad Hardened | No |
Electrical
| Dimming | :PWM | Frequency | 200kHz ~ 1MHz |
| Voltage Rating | :42V | Current - Output | :1A |
| Voltage - Supply | 6 V ~ 55 V | Number of Outputs | 3 |
| Frequency - Switching | :1MHz | Voltage - Input (Min) | :6V |
| Voltage - Supply (Min) | 6 V | Constant Current Load - Max | Yes |
| Voltage - Continuous Operating (Max) (MCOV) | :55V | ||
Mechanical
| Weight | 0 | Packaging | Tube |
| Case Color | :QFN | Lead Style | No Lead |
| Mounting Type | Surface Mount | Package / Case | 52-VQFN |
| Package Cooled | QFN EP | Package Quantity | QFN EP |
| Number of Positions | 39 | Supplier Device Package | 52-QFN (5x8) |
Product Info
| Type | Color, White LED | Topology | PWM, Step-Down (Buck) |
| Number of Segments | 30 | Internal Connection | Yes |
Environmental
| Operating Temperature | -40°C ~ 125°C | Operating Temperature - Junction | 125C |
