LT3592EMSE#PBF
| Manufacturer | |
| Description | LED DRVR 2Segment 5V/9V/12V/15V/18V/24V 10-Pin MSOP EP IC LED DRVR HP CONS CURR 10-MSOP LED 驱动器, 3.6 → 36 V, 10引脚 MSOP封装 |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | LT3592EMSEPBF | Standard Package | 50 |
| Standard Package Name | MSOP | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Rad Hardened | No | ||
Electrical
| Frequency | 400kHz ~ 2.2MHz | Voltage Rating | 3.6 |
| Voltage - Supply | 3.6 V ~ 36 V | Number of Outputs | 1 |
| Voltage - Input (Min) | 30V | Voltage - Supply (Min) | 3.6 V |
| Constant Current Load - Max | Yes | Current - Average Rectified (Io) | Yes |
| Common Mode Transient Immunity (Min) | Extended | ||
Mechanical
| Packaging | Tube | Lead Style | Gull-wing |
| Mounting Type | Surface Mount | Package / Case | 10-TFSOP, 10-MSOP (0.118", 3.00mm Width) Exposed Pad |
| Package Cooled | MSOP EP | Package Quantity | MSOP EP |
| Primary Material | Automotive, General Purpose | Number of Positions | 10 |
| Supplier Device Package | 10-MSOP-EP | ||
Product Info
| Type | Color, White LED | Topology | PWM, Step-Down (Buck) |
| Internal Switch(s) | Yes | Number of Segments | 2 |
| Internal Connection | Yes | Output Configuration | Surface Mount |
Environmental
| Operating Temperature | -40°C ~ 125°C | Operating Temperature - Junction | 125C |
