LT3571EUD#PBF

Manufacturer	Analog Devices, Inc.
Description	Conv DC-DC Single Step Up 2.7V to 20V 16-Pin QFN EP IC REG BOOST ADJ 0.47A 16QFN IC, DC/DC CONV, 75V, 16QFN
Category	Power SolutionsDC DC ConvertersNon-Isolated DC-DC Converters

对参数有疑问？问 AI 助手

Business

Other Names	LT3571EUDPBF	Standard Package	121
Standard Package Name	QFN

Compliance

RoHS	Lead free / RoHS Compliant	SVHC	:No SVHC (20-Jun-2013)
EU RoHS	Compliant	Tariff No	85423190
Rad Hardened	No

Electrical

PWM Type	Current/Voltage Mode	Frequency	:2MHz
Output Type	Adjustable	Regulator Type	:Step Up (Boost)
Voltage Rating	20 V	Current - Output	470mA
Voltage - Supply	:2.7V	Number of Outputs	1
Regulator Topology	Step Up	Switching Regulator	Yes
Frequency - Switching	250kHz ~ 2MHz	Synchronous Rectifier	No
Voltage - Input (Min)	Up to 75V	DC Voltage - Input (Min)	2.7 V
Common Mode Transient Immunity (Min)	Extended

Mechanical

Weight	0.0001	Packaging	Tube
Lead Style	No Lead	Termination	:SMD
Mounting Type	Surface Mount	Number of Pins	:16
Package / Case	16-WFQFN Exposed Pad	Package Cooled	QFN EP
Material Finish	:MSL 1 - Unlimited	Package Quantity	QFN EP
Number of Positions	16	Supplier Device Package	16-QFN-EP (3x3)

Product Info

Type

Step Up

Base Unit

:3571

Environmental

Operating Temperature

-40°C ~ 125°C
