D38999/26WB5SC

Manufacturer	Amphenol Corporation
Description	Conn MIL-DTL-38999 Circular SKT 5 POS Crimp ST Cable Mount 5 Terminal 1 Port MIL-DTL-38999 Series III Circular Connector CONN PLUG 5POS STRAIGHT W/SCKT Circular MIL Spec Connector 5P SIZE 11 STRAIGHT PLUG SOCKET CIRCULAR, SIZE 11, 5WAY, SKT
Category	Connector SolutionsCircular ConnectorsStandard Circular Connectors

对参数有疑问？问 AI 助手

Business

Part # Aliases

88-552042-05L

Standard Package

Bulk

RoHS	Contains lead / RoHS non-compliant	MIL Type	MIL-DTL-38999 III
Tariff No	85369010	Approval Agency	:MIL-DTL-38999 Series III

Voltage Rating

600VAC, 850VDC

Current Rating (Max)

7.5A

Weight	0.001	Packaging	Bulk
Shell Size	11	Orientation	C
Shell Style	straight plug	Termination	Crimp
Weight (g):	21.89500	Contact Type	socket contacts
Mounting Type	Cable Mount	Shell Plating	Olive Drab Chromate over Cadmium
Connector Type	MIL-DTL-38999 Series III Connector	Contact Finish	Gold
Fastening Type	Threaded	Mounting Style	Wire
Shell Material	Aluminum	Insertion Angle	11-5
Material - Body	:Aluminium	Shell Size, MIL	B
Contact Material	Copper Alloy	Termination Style	Crimp
1st Contact Gender	Socket (Female)	Mating Orientation	Self Locking
Number of Contacts	Yes	Contact Termination	:Crimp
Number of Positions	5	Shell Size - Insert	11-5
Shell Material, Finish	Aluminum, Olive Drab Cadmium Plated	Contact Finish Thickness	50µin (1.27µm)
1st Connector Mounting Type	:Cable

Type	MIL-DTL-38999 Circular	Gender	PL
Series	TV	Features	Shielded
Product Type	Plugs	Service Class	olive drab cadmium plate aluminum, 500 hour salt spray, EMI -50dB @ 10GHz, 175Â°C
