D38999/26JG41SN
| Manufacturer | |
| Description | Conn MIL-DTL-38999 Circular SKT 41 POS Crimp ST Cable Mount 41 Terminal 1 Port MIL-DTL-38999 Series III Circular Connector CONN PLUG 41POS STRAIGHT W/SCKT Circular MIL Spec Connector 41P PLG SZ 21 SKT CBL MNT CONNECTOR, CIRC, 21-41, 41WAY, SIZE 21 |
| Category |
Business
| Standard Package | Bulk | ||
Compliance
| RoHS | Contains lead / RoHS non-compliant | MIL Type | MIL-DTL-38999 III |
| Tariff No | 85369010 | Approval Agency | :MIL-DTL-38999 Series III |
Electrical
| Insertion Loss | Normal | Voltage Rating | 600VAC, 850VDC |
| Current Rating (Max) | 7.5A | Voltage - Supply (Min) | 1800 |
Mechanical
| Weight | 0.001 | Packaging | Bulk |
| Shielding | Yes | Shell Size | 21 |
| Wire Gauge | 24,22,20 | Orientation | N (Normal) |
| Shell Style | straight plug | Termination | Crimp |
| Contact Size | 41#20 | Contact Type | 500 cycle socket contacts |
| Housing Color | Olive Drab | Mounting Type | Cable Mount |
| Shell Plating | Olive Drab Chromate over Cadmium | Connector Type | MIL-DTL-38999 Series III Connector |
| Contact Finish | Gold | Fastening Type | Threaded |
| Mounting Style | Wire | Shell Material | Aluminum |
| Connector Style | Plug | Insert Material | Hard Dielectric |
| Insertion Angle | 21-41 | Material - Body | :Composite |
| Shell Size, MIL | G | Contact Material | Copper Alloy |
| Termination Style | Crimp | 1st Contact Gender | Socket (Female) |
| Mating Orientation | Self Locking | Number of Contacts | Yes |
| Contact Termination | :Crimp | Number of Positions | 41 |
| Shell Size - Insert | 21-41 | Bushing, Grommet Type | Silicone |
| Shell Material, Finish | Olive Drab Cadmium Plated | Contact Finish Thickness | 50µin (1.27µm) |
| 1st Connector Mounting Type | :Cable | ||
Product Info
| Type | MIL-DTL-38999 Circular | Gender | PL |
| Series | TV | Product Type | Plugs |
| Service Class | olive drab cadmium plate (175°C), 2000 hours dynamic salt spray | Specifications | MIL-DTL-38999 |
Environmental
| Ratings | I | Mechanical Life | 500 |
| Ingress Protection | Environment Resistant | Operating Temperature | 175°C |
