044 104 10002 02
| Manufacturer | |
| Description | Standard Circular Connector 2P RECEPTACLE CONN RECEPT 2POS MINI PUSH-ON connector;plastic circ;str recept housing;for 2 crimp pin cont;sealed;ip65/ip67 RECEPTACLE, SERIES 44, 2 WAY connector, plastic circ, str recept housing, for 2 crimp pin cont, sealed, ip65/ip67 |
| Category |
对参数有疑问？问 AI 助手
Business
| Product Category | Standard Circular Connector | Standard Package | 500 |
| Factory Pack Quantity | 100 | ||
Compliance
| RoHS | RoHS Compliant | SVHC | :No SVHC (16-Dec-2013) |
| Tariff No | 85369010 | ||
Electrical
| Voltage Rating | 250 V | Current Rating (Max) | 8 A |
Mechanical
| Color | Black | Weight | 0.005 |
| Packaging | Bulk | Wire Gauge | 18-14 |
| Orientation | Keyed | Shell Style | Receptacle |
| Termination | Crimp | Contact Type | Crimp |
| Mounting Type | Free Hanging (In-Line) | Angle of Throw | Straight |
| Connector Type | Receptacle for Male Contacts | Contact Finish | Silver |
| Fastening Type | Push-Pull | Mounting Style | Free Hanging |
| Package / Case | Plastic | Insertion Angle | :- |
| Material - Body | :Thermoplastic | Housing Material | Thermoplastic Rubber |
| Primary Material | Sealed | Termination Style | Crimp |
| 1st Contact Gender | :Socket | Number of Contacts | 2 |
| Dielectric Material | Santoprene | Insulation Diameter | 0.08 to 013 " |
| Number of Positions | 2 | Shell Size - Insert | :- |
| Shell Material, Finish | Plastic | 1st Connector Mounting Type | :Cable |
Product Info
| Note | Contacts Not Provided | Type | Cable Socket |
| Gender | :Socket | Series | 44 |
| Manufacturer | 44 Series | Product Type | Connectors |
| Application Specifics | Commercial | ||
Environmental
| Seal Rating | IP 67 | Ingress Protection | IP65/67 - Dust Tight, Water Resistant, Waterproof |
| Operating Temperature | :105°C | ||
Documents & Media
PDF Document
PDF Document
