ELFH03210E
| Manufacturer | |
| Description | Pluggable Terminal Blocks HORIZONTAL HEADER 5.08MM 3POS EARED Conn Shrouded Header HDR 3 POS 5.08mm Solder RA Thru-Hole TERM BLOCK HDR 3POS R/A 5.08MM Amphenol ELFH Series 5.08mm Pitch 3 Way 1 Row Right Angle PCB Header, Solder Termination, 15A Conn; Term Blk; PCB; 3; 5.08 mm; Horiz.; Black; 15 A; 300 V; w/ Locking Ears |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Headers | Other Names | APC1269 |
| Part # Aliases | 308-0197 | Product Category | Pluggable Terminal Blocks |
| Standard Package | 100 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| Current | 15A | Voltage | 300V |
| Voltage Rating | 300 V | Current Rating (Max) | 15A |
| Voltage - Input (Min) | 300V | ||
Mechanical
| Color | Black | Depth | 12.06 |
| Pitch | 0.200" (5.08mm) | Height | 8.1 |
| Packaging | Bulk | Termination | Solder |
| Housing Color | Black | Mounting Type | Right Angle |
| Contact Finish | Tin-Lead | Number of Rows | 1 |
| Contact Material | Brass | Housing Material | Polybutylene Terephthalate |
| Length - Overall | 25.4 | Termination Style | Through Hole |
| Header Orientation | 90°, Right Angle | Number of Contacts | 3 |
| Number of Positions | 3 | Terminal Block Type | Header, Male Pins, Shrouded (4 Side) |
Product Info
| Type | Shrouded Header | Gender | HDR |
| Series | ELFH | Features | Flange |
| Number of Levels | 1 | Positions Per Level | 3 |
