ELFH03210
| Manufacturer | |
| Description | Conn Shrouded Header HDR 3 POS 5.08mm Solder RA Thru-Hole TERM BLOCK HDR 3POS R/A 5.08MM Amphenol ELFH Series 5.08mm Pitch 3 Way 1 Row Right Angle PCB Header, Solder Termination, 15A Pluggable Terminal Blocks HORIZONTAL HEADER 5.08MM 3POS CLOSED Conn; Term Blk; PCB; 3; 5.08 mm; Horiz.; Black; 15 A; 300 V |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Headers | Other Names | APC1259 |
| Part # Aliases | 308-0176 | Product Category | Pluggable Terminal Blocks |
| Standard Package | Bulk | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Material Flammability Rating | UL 94 V-0 |
Electrical
| Current | 15A | Voltage | 300V |
| Voltage Rating | 300 V | Current Rating (Max) | 15A |
| Insulation Resistance | 100000 MOhms | Voltage - Supply (Min) | 300V |
Mechanical
| Color | Black | Depth | 8.1 mm |
| Pitch | 5.08 mm | Height | 12.06 mm |
| Packaging | Bulk | Termination | Solder |
| Housing Color | Black | Mounting Type | Through Hole |
| Contact Finish | Tin-Lead | Mounting Style | Through Hole |
| Number of Rows | 1 | Contact Material | Brass |
| Housing Material | Polybutylene Terephthalate (PBT) | Length - Overall | 17.06 mm |
| Termination Style | Through Hole | Header Orientation | 90°, Right Angle |
| Number of Contacts | 3 | Number of Positions | 3 |
| Terminal Block Type | Header, Male Pins, Shrouded (4 Side) | ||
Product Info
| Type | Shrouded Header | Gender | HDR |
| Series | ELFH | Number of Levels | 1 |
| Positions Per Level | 3 | ||
Environmental
| Operating Temperature | -40C to 105C | ||
