76382-308LF
| Manufacturer | |
| Description | 8 Positions Header, Shrouded Connector 0.100" (2.54mm) Through Hole, Right Angle Gold, GXT™ Pin header, Dubox 8-pin 90° 2.54 mm Poles 8 Dubox, 76382-308LF, Amphenol/FCI 08P SHROUDED HEADER 1R R/A |
对参数有疑问？问 AI 助手
Compliance
| Automotive | NO | Leadfree Defin | RoHS-conform |
| Material Flammability Rating | UL 94 V-0 | ||
Electrical
| Voltage - Test | 1000 | Voltage Rating | 250 |
| Number of Poles | 8 | Contact Resistance | ≤15 mOhm |
| Current Rating (Max) | 3 A | Insulation Resistance | 100 GOhm |
Mechanical
| Pitch | 2.54 | Packaging | TUBE |
| Pitch - Post | MALE | Number of Rows | 01 |
| Contact Material | Ni+Au | Housing Material | Glass fibre (GF) |
| Number of Contacts | 08 | 1st Connector Gender | Male |
Product Info
| Series | Dubox | Connection Method | Wire-Board |
Environmental
| Operating Temperature | -65...+125 °C | ||
Documents & Media
PDF Document
PDF Document
PDF Document
Online Document
