76382-307LF
| Manufacturer | |
| Description | 7 Positions Header, Shrouded Connector 0.100" (2.54mm) Through Hole, Right Angle Gold, GXT™ Pin header, Dubox 7-pin 90° 2.54 mm Poles 7 Dubox, 76382-307LF, Amphenol/FCI |
对参数有疑问？问 AI 助手
Compliance
| Material Flammability Rating | UL 94 V-0 | ||
Electrical
| Voltage - Test | 1000 | Voltage Rating | 250 |
| Number of Poles | 7 | Contact Resistance | ≤15 mOhm |
| Current Rating (Max) | 3 A | Insulation Resistance | 100 GOhm |
Mechanical
| Pitch | 2.54 | Contact Material | Ni+Au |
| Housing Material | Glass fibre (GF) | 1st Connector Gender | Male |
Product Info
| Series | Dubox | Connection Method | Wire-Board |
Environmental
| Operating Temperature | -65...+125 °C | ||
