Business

ProductConnectorsOther NamesACX1406
Product CategoryRF ConnectorsStandard PackageBag

Compliance

RoHSRoHS Compliant By ExemptionTariff No85366910
Rad HardenedNo

Electrical

Frequency0 to 1 GHzImpedance75 Ohm
Voltage Rating500 VCoupling FactorBayonet
Frequency - Max4 GHz

Mechanical

DepthNot Required mmHeightNot Required mm
Weight0.247623 ozDiameter12.7 mm
PackagingBulkCable Type:-
Body FinishNickelOrientationStraight
TerminationSolder PotBody MaterialBrass
Housing ColorSilverMounting TypePanel Mount
Connector TypeBulkhead Receptacle/Solder Pot TerminalsContact FinishGold
Fastening TypeBayonet LockMounting StylePanel
Plating - BodyNickelConnector StyleBNC
Contact MaterialPhosphor BronzeHousing MaterialBrass
Length - Overall30 mmTermination StyleSolder
Shield TerminationSolderContact TerminationSolder Cup
Dielectric MaterialPolytetrafluoroethylene (PTFE)Center Contact PlatingGold
Center Contact MaterialPhosphor BronzeSupplier Device PackageStraight

Product Info

TypeBNCGenderF
FeaturesIsolatedPolarityNormal
Connection TypeCoaxial CableRF Family/Standard112432

Environmental

Mating Cycles500Operating Temperature- 65 C to + 165 C
