SDKNA20700
| Manufacturer | |
| Description | Electromechanical Switch Power Switch SPDT 0.5A Pushbutton Switches .5A 125VAC QUAL LEVR Power Switches 0.5A 125V AC Qualified Power Switch SDKN Series Type: Push Circuit Arrangement: SPDT Total Travel: 9.7mm Operating Force: 21.5N Mountin Method: Snap-in Operation TypeLever Alps 单刀双掷 灰色 翘板开关, 维护, 0.5 A |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Power Switches | Product Category | Pushbutton Switches |
| Standard Package | Bulk | Factory Pack Quantity | 250 |
Compliance
| RoHS | RoHS Compliant | ||
Electrical
| Voltage Rating | 250 V | Switch Function | ON - (OFF) |
| Contact Resistance | 100mΩ | Current Rating (Max) | 500 mA |
| Voltage - Input (Max) | 5V | Voltage - Rated AC (Phase to Phase) | 250V |
Mechanical
| Packaging | Bulk | Contact Form | SPDT |
| Actuator Type | Plunger | Cable Opening | 11.2mm |
| Mounting Type | Snap In | Actuator Color | 灰色 |
| Connector Type | 插入 | Mounting Style | Through Hole |
| Termination Style | Solder Pin | Length - Below Flange | 22.9mm |
| Contact Layout, Typical | 单刀双掷 | Panel Cutout Dimensions | 22.9 x 11.2mm |
Product Info
| Type | Power Switch | Series | SDKN |
| Function | Y | Card Standard | Pushbutton Switch |
| Other Specifications | 矩形 | ||
Environmental
| Seal Rating | Unsealed | Mechanical Life | 5200Cycles |
| Operating Temperature | -20 °C | ||
