F221B3/8 CL100
| Manufacturer | |
| Description | HEATSHRINK 3/8 IN X 4FT CLEAR FIT-221 Irradiated Polyolefin Heat Shrink Tubing; 3/8" Diameter.; 4’ length; Clear; MIL-DTL-23053/5C, CLASS 1, 2 UL standard 224, CSA Standard 198. |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | 1 | ||
Compliance
| UL | NO | RoHS | Lead free / RoHS Compliant |
| Safety Category | CLEAR | Standard Number | NO |
| Military Specification | MIL-23053/5C | ||
Mechanical
| Size | 3/8 INCH | Color | Clear |
| Length | 4.00' (1.22m) | Material | Polyolefin, Irradiated |
| Cable Group | NO | Wall Thickness | SINGLE WALL |
| Material - Core | IRRPO-CROSS LINKED/IRRADIATED POLYOLEFIN | Shrinkage Ratio | 2 to 1 |
| Recovered Wall Thickness | 0.025" (0.64mm) | Inner Diameter - Supplied | 0.375" (9.5mm) |
| Inner Diameter - Recovered | 0.187" (4.8mm) | Static Discharge Shielding | YES IS SHRINK TUBING |
Product Info
| Dual | NO | Type | Tubing, Flexible |
| Features | Flame Retardant | Digit/Alpha Size | .375 INCH |
Environmental
| Shrink Temperature | 90°C | Operating Temperature | -55°C ~ 135°C |
Documents & Media
PDF Document
