F221B3/32 BK100
| Manufacturer | |
| Description | HEATSHRINK 3/32 IN X 4FT BLACK FIT-221 Irradiated Polyolefin Heat Shrink Tubing; 3/32" Diameter.; 4’ length; Black; MIL-DTL-23053/5C, CLASS 1, 2 UL standard 224, CSA Standard 198. |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | 1 | ||
Compliance
| UL | YES | RoHS | Lead free / RoHS Compliant |
| Safety Category | BLACK | Standard Number | YES |
| Military Specification | MIL-23053/5C | ||
Mechanical
| Size | 3/32 INCH | Color | Black |
| Length | 4.00' (1.22m) | Material | Polyolefin, Irradiated |
| Cable Group | NO | Wall Thickness | SINGLE WALL |
| Material - Core | IRRPO-CROSS LINKED/IRRADIATED POLYOLEFIN | Shrinkage Ratio | 2 to 1 |
| Recovered Wall Thickness | 0.020" (0.51mm) | Inner Diameter - Supplied | 0.093" (2.4mm) |
| Inner Diameter - Recovered | 0.046" (1.17mm) | Static Discharge Shielding | YES IS SHRINK TUBING |
Product Info
| Dual | NO | Type | Tubing, Flexible |
| Features | Flame Retardant, UV Resistant | Digit/Alpha Size | .093 INCH |
Environmental
| Shrink Temperature | 90°C | Operating Temperature | -55°C ~ 135°C |
