Business
| Product Category | Hook-up Wire | Standard Package | 1 |
Compliance
| RoHS | RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85444995 | ||
Electrical
| Voltage | 150V | Voltage Rating | 150 V |
| Conductor Strand | 7/34 | Current Rating (Max) | :4A |
| Number of Conductors | :7 x 0.16mm | ||
Mechanical
| Length | 1000 ft | Weight | 2 lbs |
| Packaging | Spool | Wire Type | Hook-Up/Lead Wire |
| Cable Type | Hook Up | Wire Gauge | 26 |
| Jacket Color | Yellow | Outer Diameter | :1.02mm |
| Length - Overall | :1000ft | Conductor Material | Copper, Tinned |
| Diameter - Outside | 1.02 mm | Insulation Material | Polyvinyl Chloride (PVC), Irradiated |
| Number of Cable Pairs | 7 x 34 | Wire Gauge or Range - AWG | :26AWG |
| Jacket (Insulation) Diameter | 0.039" (0.99mm) | Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) |
| Jacket (Insulation) Thickness | 0.010" (0.25mm) | ||
Product Info
| Type | Soldering Iron Resistant | Series | 7053 |
Environmental
| Ratings | UL Style 1429 | Operating Temperature | -55°C ~ 105°C |
| Maximum Temperature Limit | + 105 C | ||
Documents & Media
PDF Document
PDF Document
PDF Document
PDF Document
Sourcing & traceability
- Datasheet
- 7053 Spec Sheet
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
