Business
| Product Category | Hook-up Wire | Standard Package | 1 |
Compliance
| RoHS | RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85444995 | ||
Electrical
| Voltage | 600V | Voltage Rating | 600 V |
| Conductor Strand | 7/30 | Current Rating (Max) | :10A |
| Number of Conductors | :7 x 0.255mm | ||
Mechanical
| Length | 1000 ft | Weight | 6 lbs |
| Packaging | Spool | Wire Type | Hook-Up/Lead Wire |
| Cable Type | Hook Up | Wire Gauge | 22 |
| Jacket Color | Violet | Outer Diameter | :2.38mm |
| Material - Core | :PVC | Material Finish | :- |
| Insulation Color | :Violet | Length - Overall | :1000ft |
| Conductor Material | Copper, Tinned | Diameter - Outside | 2.39 mm |
| Insulation Material | Polyvinyl Chloride (PVC) | Number of Cable Pairs | 7 x 30 |
| Wire Gauge or Range - AWG | :22AWG | Jacket (Insulation) Diameter | 0.094" (2.38mm) |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) | Jacket (Insulation) Thickness | 0.032" (0.81mm) |
| UL Insulation System Approval | :UL1015 | ||
Product Info
| Type | Multiple UL AWM Styles | Series | 3071 |
| Number of Cores | :1 | ||
Environmental
| Ratings | UL Style 1015 | Operating Temperature | -20°C ~ 105°C |
| Maximum Temperature Limit | + 105 C | ||
Documents & Media
PDF Document
PDF Document
PDF Document
PDF Document
Sourcing & traceability
- Datasheet
- 3071 Spec Sheet
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
