3055 GR001

Manufacturer	Alpha Wire Corporation
Description	Hook-up Wire 18AWG 16/30 PVC 1000ft SPOOL GREEN HOOK-UP STRND 18AWG GREEN 1000' Wire; Hook-Up; 18 AWG; 16/30; 0.016 in.; 0.080 in.; -40 degC; 300 V; Green; 304m Hook-up Wire 1Conductors 18AWG 30.5m/305m 2.03mm Tinned Copper Green 300VAC WIRE, UL1007, 18AWG, GREEN, 305M UL 1007. POLYVINYL CHLORIDE INSULATED WIRE. GREEN. 18 AWG. 16 STRAND TINNED COPPER. 80C 300V Alpha Wire 18 AWG 绿色护套内部连线电线, 截面积 0.81 mm², 线芯绞距 16/0.25 mm, 300 V, 15 A, 305m 长, UL1007型 UL1007
Category	Cables, Wires, and ComponentsSingle Conductor CablesWire Wrap

对参数有疑问？问 AI 助手

Business

Product Category

Hook-up Wire

Standard Package

RoHS	RoHS Compliant	SVHC	:No SVHC (20-Jun-2013)
Tariff No	85444995

Length	1000 ft	Weight	7.200 lbs
Packaging	Spool	Wire Type	Hook-Up/Lead Wire
Cable Type	Hook Up	Wire Gauge	18
Jacket Color	Green	Outer Diameter	:2.03mm
Material - Core	:PVC	Material Finish	:-
Insulation Color	:Green	Length - Overall	:1000ft
Conductor Material	Copper, Tinned	Diameter - Outside	2 mm
Insulation Material	Polyvinyl Chloride (PVC)	Number of Cable Pairs	16 x 30
Wire Gauge or Range - AWG	:18AWG	Jacket (Insulation) Diameter	0.079" (2.01mm)
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)	Jacket (Insulation) Thickness	0.016" (0.41mm)
UL Insulation System Approval	:UL1007
