3055 BL001

Manufacturer	Alpha Wire Corporation
Description	Hook-up Wire 18AWG 16/30 PVC 1000ft SPOOL BLUE HOOK-UP STRND 18AWG BLUE 1000' Wire; Hook-Up; 18 AWG; 16/30; 0.016 in.; 0.080 in.; -40 degC; 300 V; Blue; 304m WIRE, UL1007, 18AWG, BLUE, 305M UL 1007. POLYVINYL CHLORIDE INSULATED WIRE. BLUE. 18 AWG. 16 STRAND TINNED COPPER. 80C 300V Alpha Wire 18 AWG 蓝色护套内部连线电线, 截面积 0.81 mm², 线芯绞距 16/0.25 mm, 300 V, 15 A, 305m 长, UL1007型 UL1007
Category	Cables, Wires, and ComponentsSingle Conductor CablesWire Wrap

对参数有疑问？问 AI 助手

Business

Product Category

Hook-up Wire

Standard Package

RoHS	RoHS Compliant	SVHC	:No SVHC (20-Jun-2013)
Tariff No	85444995

Length	1000 ft	Weight	7.200 lbs
Packaging	Spool	Wire Type	Hook-Up/Lead Wire
Cable Type	Hook Up	Wire Gauge	18
Jacket Color	Blue	Outer Diameter	:2.03mm
Material - Core	:PVC	Material Finish	:-
Insulation Color	:Blue	Length - Overall	:1000ft
Conductor Material	Copper, Tinned	Diameter - Outside	2 mm
Insulation Material	Polyvinyl Chloride (PVC)	Number of Cable Pairs	16 x 30
Wire Gauge or Range - AWG	:18AWG	Jacket (Insulation) Diameter	0.079" (2.01mm)
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)	Jacket (Insulation) Thickness	0.016" (0.41mm)
UL Insulation System Approval	:UL1007
