PL155
| Manufacturer | |
| Description | 75W 1 Output Digital Bench Power Supply, 0 to 15V, 0 to 5A UKAS (155383), PL155 Power Supply RSCAL (155383), PL155 Power Supply Pwr sup.unit: laboratory; Channels:1; 0÷15VDC; 0÷5A Laboratory Power Supply 1 Ch. 0...15 VDC 5 A, PL155, Aim-TTi Aim-TTi 台式电源, 1 输出, 0 → 15V, 0 → 5A, 75W |
| Category |
对参数有疑问？问 AI 助手
Compliance
| RoHS | Not Applicable | Safety Category | EN 61010-1 |
Electrical
| Noise | ≤0,4mVrms | Ripple | 0.4 |
| Power - Input | 230VAC 50/60Hz | Power - Rated | 75W |
| Current - Test | 1 | Voltage Rating | 0 → 15V |
| Current - Output | 0 → 5A | Voltage - Supply | 115 V ac, 230 V ac |
| Number of Outputs | 1 | Output Resolution | 0.001A |
| Power Supply Type | laboratory | Resolution (Bits) | 10 |
| Number of Channels | 1 | Current Rating (Max) | 0 → 5A |
| Voltage - Output (Max) | 15 | Voltage Regulation - Load | ≤0,01% + 2mV |
Mechanical
| Size | 288 x 107 x 131 mm | Weight | 0.4 kg |
| Connector Type | 接线柱端子 | Output Connector | Binding Post Terminal |
| Size / Dimension | 105 x 130 x 315mm | Connector - Cable | CH |
| Number of Positions | 2 | ||
Product Info
| Type | Digital | Display Style | 2x LED 4 digits |
| Number of Units | 1 | Number of Monitor Fields | 2 |
Environmental
| Operating Temperature | +5°C | Maximum Temperature Limit | +40°C |
