LPT62-M
| Manufacturer | |
| Description | PWR SUPPLY 60W 5/12/12V TRPL MED Universal input SMPSU,5V +/-12V 60W SMPSOPENFRAMELPT62-M |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | 56 | ||
Compliance
| RoHS | Compliant | Approval Agency | CE, CSA, UL, VDE |
Electrical
| Noise | 120 mV Pk-Pk, 50 mV Pk-Pk | Efficiency | 70% |
| Power (Watts) | 60W | Power - Rated | 80W |
| Voltage Rating | 120 → 300 V dc, 85 → 264 V ac | Line Regulation | ±2%, ±5% |
| Load Regulation | ±2%, ±5% | Current - Output | -12 VDC @ 700mA |
| Number of Outputs | 3 | Power Supply Type | Switching (Open Frame) |
| Power (Watts) - Max | 60W | Voltage - Input (Min) | 5V, ±12V |
Mechanical
| Depth | 42.9mm | Width | 76.2mm |
| Length | 127mm | Weight | 0.34kg |
| Mounting Type | Chassis Mount | Package Cooled | Open Frame |
| Size / Dimension | 5.00" L x 3.00" W x 1.69" H (127.0mm x 76.2mm x 42.9mm) | ||
Product Info
| Type | Standard Product | Applications | Medical |
Environmental
| Operate Time | 550000h | Operating Temperature | 0°C ~ 50°C |
| Maximum Temperature Limit | +50°C | ||
