LPT42
| Manufacturer | |
| Description | PWR SUPPLY TRPL 5/12/-12V 7A 40W LP universal input SMPSU,5V +/-12V 40W LPT42SMPS |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 454-1075 | Standard Package | 80 |
Compliance
| RoHS | Compliant | Approval Agency | CB, CE, CSA, NEMKO, UL |
Electrical
| Noise | 120 mV Pk-Pk, 50 mV Pk-Pk | Efficiency | 70% |
| Power (Watts) | 40W | Power - Rated | 40W |
| Voltage Rating | 120 → 300 V dc, 85 → 264 V ac | Line Regulation | ±2%, ±5% |
| Load Regulation | ±2%, ±5% | Current - Output | -12 VDC @ 500mA |
| Number of Outputs | 3 | Power Supply Type | Switching (Open Frame) |
| Power (Watts) - Max | 40W | Voltage - Input (Min) | 5V, ±12V |
Mechanical
| Depth | 29mm | Width | 76.2mm |
| Length | 127mm | Weight | 0.23kg |
| Mounting Type | Chassis Mount | Package Cooled | Open Frame |
| Size / Dimension | 5.00" L x 3.00" W x 1.14" H (127.0mm x 76.2mm x 29.0mm) | ||
Product Info
| Type | Standard Product | Applications | Commercial |
Environmental
| Operate Time | 550000h | Operating Temperature | 0°C ~ 50°C |
| Maximum Temperature Limit | +50°C | ||
