574502B03300G
| Manufacturer | |
| Description | Heat Sink Passive TO-220 Thru-Hole 21.2°C/W Black Anodized Heat Sinks TO-220 VERT 21.2 TR SLIDE-ON SOLDER TABS HEATSINK TO-220 VERT MNT W/TAB Heat Sink; Plug-In for TO-220; RoHS compliant Heat Sink Passive TO-220 Thru-Hole 21.2C/W Black Anodized HEAT SINK, 21.2K/W, TO-220 HeatSink,Plug-InforTO-220,RoHScompliant |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Heat Sinks | Lead Time | 56 Days |
| Other Names | HS357 | Subcategory | Heat Sink |
| Part # Aliases | 042349 | Product Category | Heat Sinks |
| Standard Package | Bulk | Factory Pack Quantity | 1000 |
Compliance
| RoHS | RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 90261089 |
| Rad Hardened | No | ||
Mechanical
| Color | Black | Depth | 9.9 mm |
| Shape | Rectangular | Width | 20.57 mm |
| Finish | Black Anodized | Height | 19.05 mm |
| Length | 9.9 mm | Weight | 0.002 |
| Material | Aluminum | Mounting Style | Through Hole |
| Package Cooled | TO-220 | Width (Inches) | :0.81" |
| Height (Inches) | :0.768" | Material Finish | Black Anodized |
| Width - Overall | :20.57mm | Length - Overall | :0.39" |
| Primary Material | TO-220 | Size / Dimension | 21.84mmLx19.05mmHx9.02mmW,0.86in.Lx0.75in.Hx0.355in.W |
| Attachment Method | Solderable Tab | Heat Sink Material | Aluminum |
| Height - Seated (Max) | 0.390" (9.91mm) | Shell Size - Insert (Convert From) | :19.5mm |
Product Info
| Type | Passive | Features | SlideonHeatSinkFeaturingSpringAction,WithSolderableTabsforVerticalMounting |
| Application | TO-220 | Application Specifics | ThroughHoleDiscreteSemiconductors |
| For Use With/Related Products | 574502B03300 | ||
Environmental
| Heat Protection | :Aluminium | Thermal Resistance | 21.2 °C/W |
| Thermal Resistance @ Natural | 21.2°C/W | Power Dissipation @ Temperature Rise | 3W @ 60°C |
| Thermal Resistance @ Forced Air Flow | 6°C/W @ 600 LFM | ||
